61 23 488 D 3474
34 D 3474.208.01.06.02 04.2010
Functions Sirona Dental Systems GmbH
Reconstructing a panoramic view Operator's Manual GALAXIS
Command
➢ Click the
"Measure Angle"
button.
or
➢ Click on the
"Measure Angle"
menu option on the
"Analysis"
/
"Measure"
menu bar.
or
➢ Press the
"[A]"
key on the PC keyboard.
ª The shape of the mouse pointer then changes to a small cross in the ap-
plicable views.
Measurement 1. Move the mouse pointer to the spot where you want to place the apex of
the angle.
2. Confirm this position by clicking the left mouse button.
3. Draw the first leg of the angle to be measured using the mouse pointer.
4. Confirm this position by clicking the left mouse button.
5. Draw the second leg of the angle by dragging the mouse pointer.
6. Confirm the angle by clicking the left mouse button.
Deleting 1. Mark the measurement with the mouse.
2. Press the Delete key on the PC keyboard.
ª The measurement is deleted.
8.10 Reconstructing a panoramic view
Explanation If the quality of the automatically generated views in the Panoramic view
workspace does not meet your diagnostic requirements, you can reconstruct
the Panoramic view workspace.
This can be done via the
"New Panorama"
dialog box.
Command
➢ Press the
"Panorama…"
button.
or
➢ Use the
"Analysis"
menu bar to select the
"Panorama…"
menu option.
ª The
"New Panorama"
dialog box appears.
Configuration The central element in the
"New Panorama"
dialog box is the display of an
axial plane of the current volume.
