61 23 488 D 3474
32 D 3474.208.01.06.02 04.2010
Functions Sirona Dental Systems GmbH
Moving the view Operator's Manual GALAXIS
8.6 Moving the view
Explanation In some cases, the complete slice plane is longer displayed after the view is
enlarged.
Using the
"Hand"
mode, you can freely move the view as required.
Any region of the slice plane can thus be displayed.
Change-over Change-over to the
"Hand"
mode can be performed in the following ways:
➢ Click the
"Hand"
button.
or
➢ Select the
"Hand"
menu option on the
"Analysis"
menu bar.
8.7 Positioning the crosshair with a single click
Explanation In certain situations, it is practical to position the crosshair at a specific loca-
tion with a single click.
Operation
1. Select the
"Crosshair"
menu option on the
"Analysis"
menu bar.
2. Click the desired position in a view.
ª All slices will then be updated to display the selected position according
to the slice orientation.
8.8 Resetting the displays
Explanation If you click the
"Back to default"
function, all views in all of the displays are
reset to their default values.
empty
Affected default values
● Navigating through slices
●Zoom
●Move
● Position of examination window
● Position of 3D view
● Contrast and brightness
Reset ➢ Use the
"Analysis"
menu bar to select the
"Back to default"
menu option.
or
➢ Enter [Ctrl] + [r] via the keyboard.
8.9 Measurements
Explanation GALAXIS offers the following measurement functions:
● Measure lengths [ ➙ 33]
● Measure angles [ ➙ 33]
