8.9.1 Measuring lengths
Explanation This function is used to indicate the distance between two selected points of
a view in millimeters.
Measuring accuracy: ± 0.15mm
Validity This measuring function can be used for the following views:
● Longitudinal view
● transversal view (TSA)
● Axial plane
● Coronal plane
● Sagittal plane
Command
➢ Click the
"Measure Distance"
button.
or
➢ Click on the
"Measure Distance"
menu option on the
"Analysis"
/
"Measu
-
re"
menu bar.
or
➢ Press the
"[D]"
key on the PC keyboard.
ª The shape of the mouse pointer then changes to a small cross in the ap-
plicable views.
Measurement 1. Place the mouse pointer at the starting point of the measurement.
2. Confirm the starting point by clicking the left mouse button.
3. Drag the mouse pointer to the desired end point.
4. Confirm the measured length by clicking the left mouse button.
Deleting 1. Mark the measurement with the mouse.
2. Press the Delete key on the PC keyboard.
ª The measurement is deleted.
8.9.2 Measure angles
Explanation This function is used to indicate the angular relationship between three selec-
ted points in a view.
The angle is indicated in degrees.
Validity This measuring function can be used for the following views:
● Longitudinal view
● transversal view (TSA)
● Axial plane
● Coronal plane
● Sagittal plane
