63 22 726 D3561
30 D3561.201.01.03.02 05.2012
3 Unit description Sirona Dental Systems GmbH
3.5 Headrest Operating Instructions SINIUS / SINIUS CS
3.5.2 Double-jointed headrest
Double-jo inted headrest
The double-jointed headrest is equipped with two rotary joints. They allow
the adjustment of head inclination for maxillary/mandibular treatment to a
great extent. The headrest extension can be pulled in or out to suit the
height of the patient.
For details, see "Adjusting the double-jointed headrest" [ → 66].
A Removable head pad with Velcro fasteners
B Rotary joints
C Unlock button (one-sided)
D Support bar for adjustment to patient height
