Sirona Dental Systems GmbH 3 Unit description
Operating Instructions SINIUS / SINIUS CS 3.8 Assistant element
båÖäáëÜ
3.8
Assistant element
Assistan t element
The functional scope of the assistant element is adapted to the dental
assistant's field of activity. It can, however, also be positioned so as to
enable unassisted treatment by the dentist.
3.8.1 Instrument positions
Instrument positions
The following instrument positions are available:
1
Only the SINIUS CS treatment center can be equipped with an intraoral
camera on the assistant element.
A Holders 1 to 4 (from left to right) for instruments
B User interfaces (left/right)
C Removable handle
D Removable instrument holder
E 3 rotary joints for flexible positioning
F Support arm
Holder 1 Holder 2 Holder 3 Holder 4
Mini L.E.D. curing light SPRAYVIT M
multifunctional syringe
Spray aspirator Saliva ejector
SiroCam AF
1
intraoral
camera
