SIUI CTS-900 - Appendix B: Touchpad Function Indication

Touchpad Function Indication
B-1
Appendix B Touchpad Function Indication
Current mode Touchpad control object Indication
Focus depth Focus
B mode unfrozen
Control window display item WCont
B mode frozen Scroll: display from frame to frame Scroll
M line position M LINE
B/M mode unfrozen
Control window display item WCont
B/M mode frozen Scroll: display from frame to frame Scroll
M mode unfrozen Control window display item WCont
M mode frozen Scroll: display from frame to frame Scroll
ZOOM mode
ZOOM frame position
Pan
ZOOM
All menus Select menu item Menu
Text input Text cursor position Text
Annotation Annotation position Annot
Patient information
input
Cursor position of input window items PAT Data
Exam type setup Cursor position of setup window items Exam
Body mark Arrow position of body mark BDYMK
Calculation Start and end points of calculation cursor Calc
Measurement Start and end points of measurement cursor Meas
Distance
measurement
Start and end points of distance measurement
cursor
Dis
Area measurement Start and end points of area measurement cursor Area
