Appendix D Acoustic Output Parameter
Transducer Model：C3I60H Operating Mode：M
TIS TIB
Non-scan
Index Label
MI
Scan
A
aprt≤1cm² Aaprt＞1cm²
Non-
scan
TIC
Global Maximum index value 0.924 0.060 0.202 0.091
Prα Mpa 1.687
P mW 6.0 6.0
Min.of[Pα(zs),Ita,α(zs)] mW
zs cm
zbp cm
zb cm 2.90
z at max. Ipi,α cm 2.95
deq(zb) cm 0.344
fawf MHz 3.332 3.332 3.332 3.332
X cm 1.92 1.92
Associated
Acoustic
parameters
Dim of
A
aprt
Y cm 1.12 1.12
td μsec 0.610
p rr Hz 512
pr at max. Ipi Mpa 2.340
deq at max. Ipi cm 0.339
Other
information
I
pi,α at max.MI W/cm² 106.38
Control 1:
Power
dB 0 0 0 0
Control 2:
Focal Depth
cm 6.0 6.0 6.0 6.0
Control 3:
M Speed
s 1.25 1.25 1.25 1.25
Operating
Control
conditions
Control 4:
Frequency
MHz 3.5 3.5 3.5 3.5 3.5
