Chapter 8
Measurement and Calculation
The user can do measurement on ultrasound images and obtain various results based on
different calculation methods; these results will be automatically and simultaneously
entered into reports for the user to generate diagnostic reports.
8.1 Key and Menu for Measurement & Calculation
8.1.1 Keys for Meas/Calc
The keys applied in measurement & calculation (Meas/Calc) and their functions are listed
in Table 8-1.
Table 8-1 Operating Keys for Measurement & Calculation and Their Functions
Key Function Description
Touchpad To select menu items in Meas/Calc menu;
To move the cursor to the measured position while calculating
and measuring.
Value control key
To move the displayed items up or down while the lines of
Meas/Calc menu or the contents in measurement result area
exceed the limited lines.
To select inputting placenta grade in OB report. To select
Prostate Echo in Prostate report.
Dis key
To measure distance In frozen B 2B, 4B and B/M modes.
Area key
To measure circumference and area in frozen B 2B, 4B and
B/M modes.
Meas key
The first press in frozen state brings up the general
measurement menu; the second press exits the measurement
menu.
Calc key
The first press in frozen state brings up the special calculation
menu; the second press exits the calculation menu.
