SIUI CTS-900 - Page 129

Acoustic Output Parameter
D-9
Transducer Model：V6I11H Operating Mode：M
TIS TIB
Non-scan
Index Label
MI
Scan
A
aprt≤1cm² Aaprt＞1cm²
Non-
scan
TIC
Global Maximum index value 0.875 0.125 0.156 0.141
Prα Mpa 2.239
P mW 4.0 4.0 4.0
Min.of[Pα(zs),Ita,α(zs)] mW
zs cm
zbp cm
zb cm 0.50
z at max. Ipi,α cm 0.95
deq(zb) cm 0.462
fawf MHz 6.541 6.541 6.541 6.541
X cm 0.66 0.66
Associated
Acoustic
parameters
Dim of
A
aprt
Y cm 0.60 0.60
td μsec 0.251
p rr Hz 512
pr at max. Ipi Mpa 2.750
deq at max. Ipi cm 0.382
Other
information
I
pi,α at max.MI W/cm² 242.88
Control 1:
Power
dB 0 0 0 0
Control 2:
Focal Depth
cm 2.1 2.1 2.1 2.1
Control 3:
M Speed
s 1.25 1.25 1.25 1.25
Operating
Control
conditions
Control 4:
Frequency
MHz 6.5 6.5 6.5 6.5
