Annotation of Image Information
7-4
In order to add an annotation, press ANNOT key to enter annotation state, then the
preset annotation phrases set according to the diagnostic part will be displayed in the list.
Use the touchpad to select the desired annotation (highlighted display) and press
Enter.
Then the selected annotation, which is now in gray, will be shifted with the cursor. Move
the cursor to the desired annotation position and press
Enter. The annotation, which is
now in white, is displayed on the position where the cursor locates.
7.2.3 System Predefined Annotations
The system predefined annotations are shown in Table 7-1 ~ Table 7-5. The user can
also add up to 15 annotations to every exam type（for more details on how to add
annotations, see Section 5.2.2.11）; In the list of annotations, the system predefined
annotations and the user-defined annotations are separated by one line.
Table 7-1 Predefined Annotations for Abdomen Application
Liver Gallbladder Pancreas
Pediatric
Abdomen
LIVER LIVER HEAD LIVER
C.HEP A SPLEEN NECK C.HEP A
SPLEEN PORTAL BODY SPLEEN
SPLENIC A PANCREAS HEP V PANCREAS SPLENIC A
PORTAL AORTA LIVER PORTAL
CELIAC CELIAC CYST CELIAC
HEP V RT KIDNEY IVC HEP V
PANCREAS
AORTA
HEP A STOMACH
PANCREAS
AORTA
SPLENIC TRANS MASS SPLENIC
HEP A SPLENIC TAIL HEP A
RT KIDNEY LT KIDNEY SMA RT KIDNEY
SMA LEFT SPLEEN SMA
LONG LONG CBD LONG
TRANS DUCT PV TRANS
LT KIDNEY IVC AO LT KIDNEY
CB SMA GB GB
DUCT GB DUCT
IVC IVC
