Use and Operation
6-7
6.1.3 Engineering Mode Function and Operation
When the panel is working in normal state, long press the engineering mode button Fn on
the panel to go to the engineering mode after the sound of “Tick-Tick Tick- Tick Tick Tick ”
sent by the console. “0” is displayed on the kV and the mAs digital tubes, which requires
inputting the engineering mode password (input “1” on the kV digital tube, or “50” on the
mAs digital tube) to enter the engineering mode. Press APR parameter button
to
enter engineering mode. The kV digital tube displays "P" + "0", which means that it has
successfully entered the engineering mode. Adjust the kV up
or down select
button on the panel to change and display the engineering mode menu number. The
functions of different menu numbers are shown in Table 6-1. Press the APR parameter
button again to confirm that the operation corresponding to the engineering mode
menu. By pressing the engineering mode button , you can return to the previous
menu and exit the engineering mode. If the parameters in the engineering mode need to
be saved, press the APR parameter button to save.
Table 6-1 Engineering Mode Menu and Functions
Menu No. Menu Menu Function
factory
defaults
P0 Manually The filament value is displayed in the kV
filament value
relevant error or device error; and the tube is ready for exposure.
When
is on, it means X-ray is emitting, and the sound of
exposure indication can be heard in the exposure.
【Caution】
The selected exposure parameters are displayed on corresponding
digital tube. To restart the device after shutting down, please make
sure that the residual energy of all energy-storage components is
completely released. Please wait until all LEDs on the circuit board go
off.
