flat side should always point to the ground unit during flight. On plane, the
standard omni antenna can stand vertically above the wings, and the antenna
flat side should always point to the ground unit during flight.
3. The air unit antenna feeder wire should be placed away from E.S.C and
motors, and any other equipment with heavy current or interference. Do not
cross or overlap the antenna feeder wires.
4. The antenna body, feeder wire, and the SMA connectors should not touch the
metal / carbon-fiber structure parts directly. Please reserve at least 1 cm
distance between these parts and the structure parts.
5. The two air unit antennas should be placed away from each other for at least
5 cm distance. And try your best to avoid any kinds of obstruction between the
ground unit and the aircraft during flight.
6. Please be very careful with the antenna wire’s SMA connectors and its solder
connectors. Do not drag them or bend them in case of any damage. To adjust
the position of the antenna, please always try to bend the middle part of the
antenna feeder wires.
CAUTION
As shown in the below pictures, on multirotor, the standard omni antennas should be
hanging vertically from the drone arms with the antenna heads pointing to ground, and the
antenna flat side should always point to the ground unit during flight.
