4. Technical data
- 26 -
951-171-016
Version 03
Part number Type of motor Manufacturer
245-13918-1 TN 63B Motori Elettrici
Rated voltage V 230 | 400 265 | 460 V AC Insulation class F
Circuit
Type of protection IP 55
Rated frequency f 50 60 Hz Flange Ø 90 mm
Rated power P 0.18 0.21 KW Operating mode S1
Rated speed n 1380 1630 rpm
-1
Size 63
Nominal current l
N
1.22 0.7 A Design B14
Starting current 2.6 x rated current A Shaft Ø 11x 23 mm
Performance factor
cos j
0.68 Ratio i 490
Efficiency
h
54.3 %
