SKF LINCOLN ZPU 01 Version E - Motors 500 V AC

4
EN
4. Technical data
- 27 -
951-171-016
Version 03
4.4 Motors 500 V AC
Part number Type of motor Manufacturer
245-13919-1 TN 63B Motori Elettrici
Rated voltage V 290 | 500 V AC Insulation class F
Type of protection IP 55
Rated frequency f 50 Hz Flange Ø 90 mm
Rated power P 0.18 KW Operating mode S1
Rated speed n 1360 rpm
-1
Size 63
Nominal current l
N
1.0/0.6 A Design B14
Starting current 2.5 x rated current A Shaft Ø 11x 23 mm
Performance factor
cos j
0.69
Efficiency
h
62 % Motor for gear M100 | M490
Part number Type of motor Manufacturer
245-13120-1 TN63 Neri
Rated voltage V 290 | 500 V AC Insulation class F
Type of protection IP 55
Rated frequency f 50 Hz Flange Ø 90 mm
Rated power P 0.25 KW Operating mode S1
Rated speed n 1400 rpm
-1
Size 63
Nominal current l
N
2.0/1.2 A Design B14
Starting current 2.5 x rated current A Shaft Ø 11x 23 mm
Performance factor
cos j
0.55
Efficiency
h
62 % Motor for gear M049
