SKF LINCOLN ZPU 01 Version E - Bridge Assy. for Version F with Two Pump Elements; Bridge Assy. for Version V with One Pump Element

EN
14. Spare parts
- 54 -
951-171-016
Version 03
14.12 Bridge assy. for version F with two pump elements
Designation Qty. Part number
Bridge assy. for version F with two pump elements 350 bar
Bridge assy. for version F with two pump elements 400 bar
Consisting of:
Item 1 Bridge with filter block and pressure gauge
Item 2 Valve assy.
Item 3 Pump cylinder assy.
Item 4 Sealing ring (2x)
1 600-26788-1
1
1
1
2
2
600-77913-1
Fig. 24
Fig. 25
14.13 Bridge assy. for version V with one pump element
Designation Qty. Part number
Bridge assy. for version V with one pump element 350 bar
Bridge assy. for version V with one pump element 400 bar
Consisting of:
Item 1 Bridge with filter block and pressure gauge
Item 2 Valve assy.
Item 3 Pump cylinder assy.
Item 4 Sealing ring (2x)
Item 5 Blind cylinder
Item 6 Locking screw
Item 7 O-ring (2x)
1 600-26785-1
1
1
1
1
2
1
1
2
600-77914-1
