Crushing hazard
on the rotating stirring paddle. Fill-
ing via the reservoir lid is allowed
only after disconnecting the pump
from the power supply. Never
reach into the reservoir while the
Make sure that no dirt enters
the reservoir during the filling
procedure.
• Switch the pump off.
• Open the reservoir lid (1a).
• Remove contaminations from the res-
ervoir lid and from the ultrasonic sen-
sor, if any.
Filling via the reservoir lid Fig. 8
In case of reservoirs with ultra-
sonic sensor:
The ultrasonic sensor must not
get in contact with lubricant.
The distance between the lubri-
cant and the ultrasonic sensor
must be at least 60 mm.
• Fill the reservoir
• Close the reservoir lid (1a).
• Switch the pump on again.
1 a
