4. Technical data
- 29 -
951-171-016
Version 03
Part number Type of motor Manufacturer
245-13923-1 TN 63B Varvel
Rated voltage V 290 | 500 V AC Insulation class F
Circuit
Type of protection IP 55
Rated frequency f 50 Hz Flange Ø 90 mm
Rated power P 0.18 KW Operating mode S1
Rated speed n 1360 rpm
-1
Size 63
Nominal current l
N
1.0/0.6 A Design B14
Starting current 2.5 x rated current A Shaft Ø 11x 23 mm
Performance factor
cos j
0.68 Ratio i 490
Efficiency
h
54 %
