TUNE YOUR RIDE
ACTION RESULT
More track surface on
the ground
Increasing
preload
Less extension lift
Better reverse capability
especially in deep snow
Decreasing
preload
More extension lift
mmo2008-005-019_a
TYPICAL
1. Spring
2. Adjustment cam
Rear Suspension Extension
Stabilizer Cam
Stabilizer cam is used to control the
suspension extension stroke.
Stabilizer cam setting has an effect on
manoeuvrability, traction and reverse
capability.
CAM
SETTING
RESULT
Allows free movement of
the suspension extension
on its entire stroke
General use
Free
Good reverse capability
Sets the suspension
extension partially lifted
and allows upwards
movement
Better manoeuvrability on
hard snow
Better fuel efficiency
Partial lift
Good reverse capability
Locks the suspension
extension in line with the
suspension rails
Better traction, full track
contact surface
Locked
Better towing capability
mmo2010-007-023_a
FREE
1. Adjustment cam
2. Lower stop block
56
