Chapter: 7. System Specications
Environmental according to IEC 60945:
Transducer and Junction Box
Operating temperature
-15 to +55 degrees C.
Storage temperature
-20 to +70 degrees C.
Protection, transducer
6 bar.
Protection, junction box
IP 56.
Operator Unit Cabinet
Supply voltage
115 V AC (96 to 125 V), 230 V AC (195 to 253 V).
24V DC (20 to 32 V). (Automatic switch over).
Power consumption
App. 60 W at 24 V, App. 80 W at 115 V or 230 V.
Alarm relay
Change-over contact, max. 24 V 300 mA.
Printer
25 pin D-type connector, (female).
NMEA port
9 pin D-type connector, (female). 2 Inputs, 2 Outputs.
Operating temperature
-15 to +55 degrees C. (To increase serviceability and life-time, we suggest the
working temperature to be held at 0 to +40 degrees C).
Storage temperature
-20 to +70 degrees C.
Humidity
10 to 90 % relative, no condensation.
Protection
IP 42.
Measuring accuracy
Better than 1 %.
