136
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 5 – Procedures Base
Charger Proles
IMPORTANT
Charge proles differ depending on the battery
type and manufacturer. Only use charge proles
with the batteries they were designed for. Using
other incompatible batteries may cause poor
charging performance and a decreased battery
health.
1. Place the charger near a power outlet, but leave it
unplugged.
2. Find your battery type in the following chart, and
make a note of the prole number (starting with
P).
3. Press and hold the Select Charger Prole button
(wrench icon) on the Delta-Q charger. You will
hear a small click when you press the button.
4. Continue to hold the Select Charger Prole
button, and connect the charger to a power outlet.
5. Continue to hold the button for approximately 10
seconds or until the Error Indicator turns orange
and the Battery Charging Indicator starts ashing
green.
6. The current charger prole displays up to three
times.
NOTE
The process times out and the prole remains
unchanged if there are 15 seconds of inactivity, or
if the charging prole is allowed to display three
times
7. Press and release the button to scroll through the
charging proles.
8. Select a prole, and press and hold the button for
10 seconds or until the Error Indicator and Battery
Charging Indicator lights turn off.
9. Press the button again to conrm the selected
prole.
10. Disconnect the charger from the power outlet.
Battery Brand Compatible with Proles
U.S. Battery - US 2200 XC/XC2 Flooded, 6V, 232 Ah 200 - 255 Ah ooded #11 (P-0-1-1)
East Penn - 8GGC2 Gel, 6V, 180 Ah 150 - 230 Ah gel #26 (P-0-2-6)
Discover Energy - EVGC6A-A AGM, 6V, 220 Ah
220 - 400 Ah AGM #43 (P-0-4-3)
Discover Energy - EV12A-A AGM, 12V, 140 Ah*
U.S. Battery - US 12V XC2 Flooded, 12V, 155 Ah*
330 - 425 Ah ooded #73 (P-0-7-3)
U.S. Battery - US 250 XC/XC2 Flooded-lead, 6V, 255 Ah
Trojan - T105 ELPT Flooded, 6V, 225 Ah 150 - 250 Ah 6V, 8V, 12V ooded #3 (P-0-0-3)
*The batteries used for these charger proles are connected in a series-parallel circuit.
