SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 2 – Maintenance Tables and Diagrams Specications & Features - KC
2.10 Specications & Features - KCTable
* Weight with standard 0.9 m extension platform. Refer to serial nameplate for speci c applications.
Note:
Emission sound pressure level does not exceed 70 dB(A)
Models 3220 3226 4720 4726 4732
Weight* 1776 kg 1900 kg 2040 kg 2135 kg
2484 kg
Overall Width 0.84 m 1.20 m
Overall Length
(Platform Retracted)
2.33 m 2.33 m
Overall Length
(Platform Extended)
3.17 m 3.47 m
Platform Size, Inside
(Platform Retracted)
0.70 m x 2.10 m 1.06 m x 2.10 m
Platform Size Inside
(Platform Extended)
0.70 m x 2.95 m 1.06 m x 3.24 m
Height
Working Height
7.95 m 9.79 m 7.95 m 9.82 m 11.65 m
Platform Elevated Height
5.95 m 7.79 m 5.95 m 7.82 m 9.65 m
Stowed Height
(Railings Down)
1.75 m 1.93 m 1.99 m 1.90 m 1.99 m
Stowed Height
(Railings Up)
2.10 m 2.29 m 2.10 m 2.29 m 2.38 m
Drive Height FULL
Standard Operating Times
Lift Time (No Load) 24 s 45 s - 46 s 47 s
Lower Time (No Load) 32 s 49 s - 43 s 36 s
Lift Time (Rated Load) 28 s 47 s - 52 s 50 s
Lower Time (Rated Load) 24 s 41 s - 32 s 30 s
Chassis
Normal Drive Speed 3.70 km/h 2.84 km/h
Elevated Drive Speed 0.97 km/h 0.97 km/h
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber) 16 x 5 x 12
Hydraulic Oil
Type
ATF DEXRON III
SHELL NATURELLE HF-E 32
Tank Capacity (Liters) 30.3 L
Brake Hub Oil
Type SAE 20W
Quantity 180 mL
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A)
1892AA
