Dual Lift Cylinder Manifold MB3 & MB4 - SJ3226, SJ4726/32 Section 3 – System Component Identication and Schematics
3.11 Dual Lift Cylinder Manifold MB3 & MB4 - SJ3226, SJ4726/32
M195800AC_CylinderManifolds
To
Lower Cylinder
2H-13-1
Holding Valve
R4
Relief Valve
2H-13-2
Holding Valve
R3
Relief Valve
To Main Manifold
3H-14
PT1
Pressure Transducer
To Upper Lift Cylinder
MB3
MB4
