Skyjack SJ4732 - Electrical Parts List

51
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Electrical Parts List Section 3 – System Component Identication and Schematics
Index
No.
Skyjack
Part No.
Description
2H-13-1 104410 COIL, 12 Volt - Upper Cyl. Holding Valve
2H-13-2 104410 COIL, 12 Volt - Lower Cyl. Holding Valve
3H-14 105610 COIL, 24 Volt - Lift
4H-15 153334 COIL, 24 Volt - Reverse
4H-16 153334 COIL, 24 Volt - Forward
3H-17 103605 COIL, 24 Volt - Brake
4H-23A 153334 COIL, 24 Volt - Right Steer
4H-24A 153334 COIL, 24 Volt - Left Steer
2H-18A 103605 COIL, 24 Volt - Differential
3H-18A-1 103605 COIL, 24 Volt - Speed A
3H-18A-2 103605 COIL, 24 Volt - Speed B
4H-26 103605 COIL, 24 Volt - Powerdeck Extend (ANSI/CSA Only)
4H-27 103605 COIL, 24 Volt - Powerdeck Retract (ANSI/CSA Only)
AT1 220597 TRANSDUCER, Angle
B1-4 103480 BATTERY, 6V - US 2200
106552 BATTERY, 6V - US 250
160933 BATTERY, 6V - AGM
168109 BATTERY, 6V - T-105
BC1 122093 INDICATOR, Battery Charge
BP29 170620 BEEPER, All Motion, Tilt & Overload
C1 146475 CONTACTOR, Motor
CB1 117325 BREAKER, Circuit - 15A
CB2 408526 BREAKER, Circuit - 10A
CM1 217926 CONTROLLER, Skycoded Module
DCM1 169260 MOTOR
DXX 102921 DIODE
F1 310517 FUSE, 300A
F2 146442 FUSE, 100A
FL-22 235775 LIGHT, Flashing
H1 146649 Horn
LS1 210226 LIMIT SWITCH, Pothole Protection - Hydraulic Tray Side
LS2 210227 LIMIT SWITCH, Pothole Protection - Battery Tray Side
PL-1 147061 LIGHT, Platform - Emergency Stop/Overload
PL-2 147061 LIGHT, Base - Emergency Stop/Overload
PT1 217934 TRANSDUCER, Pressure - 3000 PSI (SJ3220, SJ4720/26/32)
217933 TRANSDUCER, Pressure - 2000 PSI (SJ3226)
S1 210051 SWITCH, Main Disconnect
S2 147054 SWITCH, Lift/Lower
S3 207741 SWITCH, Lift/Off/Drive
S4 147053 SWITCH, Platform - Emergency Stop
S5 220494 SWITCH, SGLE
3.5 Electrical Parts List
