50
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 3 – System Component Identication and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
MB3 208583 MANIFOLD, Dual Lift Cylinder- Upper
MB4 208582 MANIFOLD, Dual Lift Cylinder- Lower
MB5 208585 MANIFOLD, Single Lift Cylinder
MB6 136540 MANIFOLD, Brake (SJ4720/26/32 CE, AS, KC)
O1 105811 ORIFICE, Steering - 0.040”
O2 141518 ORIFICE, 0.031”
O3 104434 ORIFICE, Differential - 0.040”
O4 228015 ORIFICE, 0.081” (SJ3220 ANSI/CSA, AS, KC)
228013 ORIFICE, 0.089” (SJ3220, SJ4720/32 CE)
228014 ORIFICE, 0.106” (SJ4720/26/32 ANSI/CSA, AS, KC)
O5 228014 ORIFICE, 0.106” (SJ3226 ANSI/CSA, AS, KC)
130407 ORIFICE, Brake - 0.106” (SJ4720/26/32 ANSI/CSA)
O6 130407 ORIFICE, Brake - 0.051” (SJ3220/26 ANSI/CSA)
P1 161936 PUMP, DC Motor (SJ3220/26, SJ4720/26/32 ANSI/CSA, AS, KC)
165610 PUMP, DC Motor (ANSI/CSA EE-Rated)
161938 PUMP, DC Motor (SJ4720/26/32 CE)
P2 165932 PUMP, Hand (SJ3220/26 CE, AS, KC)
146559 PUMP, Hand (SJ4720/26/32 CE, AS, KC)
QD1 122420 QUICK DISCONNECT (SJ3220/26, SJ4720/26/32 CE, AS, KC)
R1 104534 RELIEF, Main
R2 104534 RELIEF, Lift
R3 220449 RELIEF, Scissor
R4 220449 RELIEF, Scissor
SN1 210292 SNUBBER, 5um
V1 103136 VALVE, Free-wheel (SJ3220/26, SJ4726/32 ANSI/CSA)
113752 VALVE, Brake Override (SJ3220/26 CE, AS, KC)
146561 VALVE, Brake Override (SJ4720/26/32 CE, AS, KC)
V2 103136 VALVE, Free-wheel (SJ3220/26, SJ4720/26/32 CE, AS, KC)
