Skyjack SJ4732 - Telematics Harness

A B C D E F G H
V
Z
Y
X
W
82
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
3.34 Telematics Harness
M228875AE
TO CONTROLLER
19D - WHITE/RED (P1-4)
CANH - YELLOW (P1-5)
CANL - GREEN (P1-6)
CANL
CANH
19D
08C
J1
SCANL1
SCANH1
TO BATTERY NEGATIVE
00 - WHITE
00
05B
TO FUSE SUPPLIED WITH TRACKUNIT
05B - PURPLE/BLACK
CANL
CANH
TO CHARGER
CANH - YELLOW
CANL - GREEN
CANL CANH
05B
00
TO BMS HARNESS
00 - WHITE
05B - PURPLE/BLACK
CANL - GREEN
CANH - YELLOW
SCANL2
SCANH2
S00
S05
08C 08D
S08C
S08D
PIN 1 - PLUGGED
PIN 2 - 08D PURPLE/WHITE
PIN 3 - 05B PURPLE/BLACK
PIN 4 - 00 WHITE
PIN 5 - PLUGGED
PIN 6 - PLUGGED
PIN 7 - CANH YELLOW
PIN 8 - CANL GREEN
PIN 9 - 19D WHITE/RED
PIN 10 - PLUGGED
PIN 11 - PLUGGED
PIN 12 - PLUGGED
J1
BACK VIEW
1
2
3
4
5
6
7
8
9
10
11
12
3
2 4
1 6
7
8
9 10
11
12
5
IEC 9.1
J1
TO TRACKUNIT
TO BATTERY TO BMS
TO CHARGER
CANH-YL-20-STP
CANL-GN-20-STP
08C-PU/WH-18
19D-WH/RD-18
CANL-GN-20-STP
CANH-YL-20-STP
CANL-GN-20-STP
CANH-YL-20-STP
00-WH-18
05B-PU/BK-18 05B-PU/BK-18
00-WH-18
CANL-GN-20-STP
CANH-YL-20-STP
00-WH-18
05B-PU/BK-18
08D-PU/WH-18
19D-WH/RD-18
SCANH1
SCANL1
S00
S05B
SCANH2
SCANL2
1A FUSE
S08C S08D
