SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Specications & Features - ANSI/CSA Powerdeck and ACPP Section 2 – Maintenance Tables and Diagrams
* Weight with standard 0.9 m extension platform. Refer to serial nameplate for speci c applications.
Note:
Emission sound pressure level does not exceed 70 dB(A)
Models 3220 Powerdeck 4726 Powerdeck 4726 ACPP
Weight*
1952 kg
4304 lb
2625 kg
5788 lb
2703 kg
5960 lb
Overall Width
0.84 m
2 ft 9 in
1.38 m
4 ft 6-5/16 in
1.38 m
4 ft 6-5/16 in
Overall Length
(Platform Retracted)
2.37 m
7 ft 9-7/16 in
2.37 m
7 ft 9-7/16 in
2.55 m
8 ft 4-1/4 in
Platform Size, Inside
(Platform Retracted)
0.70 m x 2.10 m
2 ft 3-9/16 in x 6 ft 10-3/4 in
1.06 m x 2.12 m
3 ft 5-7/8 in x 6 ft 11-3/8 in
1.06 m x 2.12 m
3 ft 5-7/8 in x 6 ft 11-3/8 in
Platform Size Inside
(Platform Extended)
0.70 m x 3.86 m
2 ft 3-9/16 in x 12 ft 7-7/8 in
1.06 m x 3.86 m
3 ft 5-7/8 in x 12 ft 7-7/8 in
1.06 m x 3.86 m
3 ft 5-7/8 in x 12 ft 7-7/8 in
Height
Working Height
7.78 m
25 ft 6-1/4 in
9.65 m
31 ft 8 in
9.65 m
31 ft 8 in
Platform Elevated Height
5.95 m
19 ft 6-1/4 in
7.82 m
25 ft 8 in
7.82 m
25 ft 8 in
Stowed Height
(Railings Down)
1.75 m
5 ft 9 in
1.90 m
6 ft 2-7/8 in
-
Stowed Height
(Railings Up)
2.10 m
6 ft 10-7/8 in
2.29 m
7 ft 6 in
2.31 m
7 ft 6-7/8 in
Drive Height FULL
Standard Operating Times
Lift Time (No Load) 24 s 46 s 46 s
Lower Time (No Load) 32 s 43 s 43 s
Lift Time (Rated Load) 28 s 52 s 52 s
Lower Time (Rated Load) 24 s 32 s 32 s
Chassis
Normal Drive Speed
3.88 km/h
2.4 mph
3.24 km/h
2.0 mph
3.24 km/h
2.0 mph
Elevated Drive Speed
0.97 km/h
0.6 mph
0.97 km/h
0.6 mph
0.97 km/h
0.6 mph
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber) 16 x 5 x 12
Hydraulic Oil
Type
ATF DEXRON III
SHELL NATURELLE HF-E 32
Tank Capacity (Liters) 30.3 L (8 gal)
Brake Hub Oil
Type SAE 20W
Quantity 180 mL (6.09 oz)
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A)
