Skyjack SJ4732 - Anti-Overrising Harnesses (KC Only)

68
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 3 – System Component Identication and Schematics Anti-Overrising Harnesses (KC Only)
M212440AB_M220079AA
CAVITY COLOUR
LABEL
TERMINATION
1
GREEN 08 C TERM. MALE 18-22 GA
2 NOT USED
3
WHITE 51A FEMALE WIRE PIN
4 BLACK
51 FEMALE WIRE PIN
Anti-Overrising Posts - Scissor Harness
ID #
COLOUR
LABEL
1
GREEN 08C
2 NOT USED
3
WHITE 51A
4 BLACK
51
ID #
COLOUR
LABEL
1
GREEN 08C
2
RED
52A
3
WHITE 51A
4 BLACK
51
1
2
4
3
ID #
COLOUR
LABEL
1
GREEN 08C
2 BLACK 08C
3
WHITE 51A
4
RED
52A
1
2
4
3
3
4
2
1
3
4
2
1
3
4
2
1
51A - WHITE
51 - BLACK
52A - RED
51A - WHITE
51 - BLACK
08C - GREEN
08C - GREEN
52A - RED
51A - WHITE
08C - BLACK
08C - GREEN
S51A
S08C
SCHEMATIC VIEW
Anti-Overrising Posts - Platform Harness
3.22 Anti-Overrising Harnesses (KC Only)
