Skyjack SJ4732 - Platform Control Box Wiring

59
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Platform Control Box Wiring Section 3 – System Component Identication and Schematics
3.13 Platform Control Box Wiring
M212617AC
08
08
08
08
08
S27 - TORQUE
S3 - LIFT/OFF/DRIVE
S8 - HORN
S4 - EMERGENCY STOP
08
D08-1
GREEN/BLACK - TIED BACK
BC1 - BATTERY CHARGE INDICATOR
12
09
18
49
60
00
08
07
08
16 15 14 13 12 11 10
91
2 3 4 5 6 7 8
1 2
3
4
5
6 7 8
PIN NO. COLOUR CIRCUIT NO.
1 WHITE 00
2
BLUE
12
3 ORANGE 09
4
BLACK 08A
5
RED 07
6
BLUE/WHITE
08
7
GREEN/WHITE
49
8 GREEN 08B
9 NOT USED
10
WHITE/BLACK
00B
11
RED/BLACK
18
12
ORANGE/BLACK
59
13
GREEN/BLACK
TIED BACK
14
BLUE/BLACK
24
15
BLACK/WHITE
23
16
RED/WHITE
60
PIN NO. LABEL DESCRIPTION CTRL BOX HARNESS JOYSTICK HARNESS
1
24
LEFT
BLUE/BLACK WHITE/RED
2
NONE
N/C N/C N/C
3 23 RIGHT
BLACK/WHITE
WHITE
4
08A ENABLE OUT BLACK
WHITE/BLUE
5
08 24V SUPPLY
PURPLE/WHITE WHITE/BLACK
6 00B 0V SUPPLY
WHITE/BLACK
GREY
7
59 PROP. OUT
ORANGE/BLACK
BLUE
8 08B 5V SUPPLY GREEN YELLOW
P10
TO S7 JOYSTICK
