Skyjack SJ4732 - Outdoor Switch Wiring and Harness (SJ3226 ANSI;CSA Only)

73
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Outdoor Switch Wiring and Harness (SJ3226 ANSI/CSA Only) Section 3 – System Component Identication and Schematics
3.26 Outdoor Switch Wiring and Harness (SJ3226 ANSI/CSA Only)
CAVITY COLOUR
LABEL
TERMINATION
1
GREEN 08 C TERM. MALE 18-22 GA
2 NOT USED
3
WHITE 51A FEMALE WIRE PIN
4 BLACK
51 FEMALE WIRE PIN
1
2
3
00
BK
RD
120
08C
TO "B -"
CONTROLLER
120
TO "P3-4"
CONTROLLER
00
TO "08C"
MAIN HARNESS
08C
COLOUR DESCRIPTION
GREEN 08C
WHITE
00
BLACK 120
