Skyjack SJ4732 - Powerdeck Harnesses

70
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 3 – System Component Identication and Schematics Powerdeck Harnesses
3.24 Powerdeck Harnesses
M207879AD_M209557AC_M216663AC
PIN NO. COLOUR LABEL NO.
1
BLACK 27
2
WHITE
08C
3 GREEN 26
4 N/A N/A
5
N/A N/A
CIRCUIT #
COLOR
TERMINAL
DESCRIPTION
8C
WHITE
MALE SPADE
TO POWERDECK
HARNESS
26 GREEN FEMALE SPADE
27 BLACK MALE SPADE
1
2 3
4
5
PIN NO. COLOUR LABEL NO.
1
BLACK 27
2
WHITE
08C
3 GREEN 26
4 N/A N/A
5
N/A N/A
CIRCUIT #
COLOR
TERMINAL
DESCRIPTION
8C
WHITE
MALE SPADE
TO POWERDECK
HARNESS
26 GREEN FEMALE SPADE
27 BLACK MALE SPADE
1
2 3
4
5
CIRCUIT #
COLOR DISCRIPTION
26 GREEN TO PIN8 ON CONTROLLER P4
27 BLACK TO PIN9 ON CONTROLLER P4
CIRCUIT #
COLOR DISCRIPTION
8C
WHITE
TO POWERDECK
CONTROL BOX
HARNESS
26 GREEN
27 BLACK
SJ3220 Powerdeck Control Box
SJ4726 Powerdeck Control Box
Powerdeck
