Skyjack SJ4732 - Specifications & Features - ANSI;CSA

32
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732223198ABA
Section 2 – Maintenance Tables and Diagrams Specications & Features - ANSI/CSA
2.6 Specications & Features - ANSI/CSATable
* Weight with standard 0.9 m extension platform. Refer to serial nameplate for speci c applications.
Note:
Emission sound pressure level does not exceed 70 dB(A)
Models 3220 3226 4726 4732
Weight*
1776 kg
3917 lb
1900 kg
4190 lb
2511 kg
5537 lb
2484 kg
5476 lb
Overall width
0.84 m
33 in
1.20 m
47.29 in
Overall length
(Platform Retracted)
2.33 m
91.61 in
Platform Size Inside
(Platform Extended)
0.7 m x 2.10 m
27.56 in x 82.75 in
1.06 m x 2.10 m
41.85 in x 82.75 in
Height
Working Height
7.78 m
25 ft 6.1 in
9.62 m
31 ft 7 in
9.65 m
31 ft 8 in
11.48 m
37 ft 8 in
Platform Elevated
Height
5.95 m
19 ft 6.1 in
7.79 m
25 ft 7 in
7.71 m
25 ft 7 in
9.65 m
31 ft 8 in
Stowed Height
(Railings Down)
1.75 m
68.96 in
1.93 m
76.08 in
1.90 m
74.84 in
1.99 m
78.45 in
Stowed Height
(Railings Up)
2.10 m
82.85 in
2.29 m
89.95 in
2.29 m
89.95 in
2.38 m
93.58 in
Drive Height FULL
Standard Operating Times
Lift Time (No Load) 24 s 45 s 46 s 47 s
Lower Time (No Load) 32 s 49 s 43 s 36 s
Lift Time (Rated Load) 28 s 47 s 52 s 50 s
Lower Time (Rated Load) 24 s 41 s 32 s 30 s
Chassis
Normal Drive Speed
3.88 km/h
2.4 mph
3.24 km/h
2.0 mph
Elevated Drive Speed
0.97 km/h
0.6 mph
0.97 km/h
0.6 mph
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber) 16 x 5 x 12
Hydraulic Oil
Type
ATF DEXRON III
SHELL NATURELLE HF-E 32
Tank Capacity (Liters) 30.3 L (8 gal)
Brake Hub Oil
Type SAE 20W
Quantity 180 mL (6.09 oz)
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A)
1900AA
