23
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
General Inspections Section 1 – Scheduled Maintenance
1
1
Center Pin - Outer
Center Pin - Middle
Center Pin - Inner
Examples of damaged pin connections:
Broken retainer bolt
Rust around the pin Rotated pin
Rust around pin boss
Stress cracksBroken pin boss
Thrust washer
