Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 11
1.1 Platform
Index
No.
Skyjack
Part No.
Qty. Description
A 161006 - PLATFORM ASSEMBLY - 5’ Drop Bar (ANSI/CSA)
B 161007 - PLATFORM ASSEMBLY - 5’ Swing Gate (ANSI/CSA)
C 161008 - PLATFORM ASSEMBLY - 5’ Drop Bar (CE& AS)
D 161009 - PLATFORM ASSEMBLY - 5’ Swing Gate (CE & AS)
E 161010 - PLATFORM ASSEMBLY - 6’ Drop Bar (ANSI/CSA)
F 161011 - PLATFORM ASSEMBLY - 6’ Swing Gate (ANSI/CSA)
G 161012 - PLATFORM ASSEMBLY - 6’ Drop Bar (CE & AS)
H 161013 - PLATFORM ASSEMBLY - 6’ Swing Gate (CE & AS)
1 (Ref.) 1 • RAILING & BASE ASSEMBLY
(For components, refer to Section 1.2)
2 159456 1 • RAILING, Side B, D, F, H
3 (Ref.) 1 • GATE, Swing B, D, F, H
(For components, refer to Section 1.3)
(Ref.) 2 • GATE, Drop A, C, E, G
(For components, refer to Section 1.4)
4 138696 1 • BOLT, Hex head (1”-8 x 10 1/2” Grade 8, zinc)
5 103866 4 • BOLT, Hex head (5/16”-18 x 2.25”, Grade 5) B, D, F, H
6 138559 1 • NUT, Torque lock (1”-8 Grade 8)
7 102646 1 • WASHER, Flat (1”)
8 125959 8 • WASHER, Flat (3/8”)
9 103996 8 • WASHER, Flat (5/16”) B, D, F, H
10 103984 4 • NUT, Hex head nylon lock (5/16”-18, Grade 5) B, D, F, H
11 139193 8 • BOLT, Hex head (3/8”-16 x 0.78”, Grade 8) A, C, E, G
