Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 223
9.10 Oil Cooler Assembly (No Generator) - 46AJ
Index
No.
Skyjack
Part No.
Qty. Description
A 166729 1 OIL COOLER ASSEMBLY (No Generator) (46AJ ANSI/CSA & AS)
B 170485 1 OIL COOLER ASSEMBLY (No Generator) (46AJ CE)
- 166736 1 • OIL COOLER ASSEMBLY
1 162962 1 • • BRACKET, Mount
2 162967 1 • • BRACKET, Mount
3 162964 1 • • BRACKET, Oil cooler mount RH
4 162963 1 • • BRACKET, Oil cooler mount LH
5 160800 1 • • OIL COOLER, 12V DC
6 103472 26 • • WASHER, Flat (0.375”)
7 103870 4 • • BOLT, Hex head (0.375”-16 x 1.50” Grade 5)
8 104606 12 • • NUT, Hex head nylon lock (0.375”-16 Grade 5)
9 103871 2 • • BOLT, Hex head (0.375”-16 x 1.75” Grade 5)
10 103596 2 • • BOLT, Hex head (0.375”-16 x 2.00” Grade 5)
11 101297 6 • • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
12 (Ref.) 1 • DRIVE/SYSTEM PUMP
(For components, refer to Section 7.6)
13 (Ref.) 1 • OIL COOLER HOSE KIT
(For components, refer to Section 9.12)
14 (Ref.) 1 • OIL COOLER WIRING (not shown)
(For components, refer to Section 9.13)
15 105445 2 • FITTING, Elbow 90° (12 JICM - 12 ORBM)
16 703284 1 • FITTING, Elbow 90° (12 JICM - 12 JICFSW)
17 112366 1 • FITTING, Elbow 90° (08 JICM - 12 ORBM)
18 162293 1 • PAD, Guide (5.00” x 2.00” x 0.625”)
19 101297 2 • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
20 103472 2 • WASHER, Flat (0.375”)
21 144238 2 • NUT, Torque lock (0.375”-16 Grade C)
22 168619 1 • SHROUD, Upper, A
170446 1 • SHROUD, Upper, B
23 168622 1 • SHROUD, Lower, A
170447 1 • SHROUD, Lower, B
24 137625 62” • SEAL, Bulb, A
137625 60” • SEAL, Bulb, B
25 101632 4 • BOLT, Hex head (0.375”-16 x 0.75” Grade 5)
26 103472 4 • WASHER, Flat (0.375”), A
127067 4 • WASHER, Flat BB style (0.375”), B
27 138981 1 • FITTING, Elbow 90° (10 JICM - 12 ORBM)
AB
