Skyjack SJ51AJ Parts Manual

SKYJACK, Page 188 Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
8.1 Standard Hose Numbering System
H1104 0081 2
FITTING
ARRANGEMENT
(See Schedule
Below)
HOSE SIZE
(See Chart
Below)
LENGTH OF HOSE IN
WHOLE INCHES
LENGTH IN
FRACTIONS (1/4”
INCREMENTS) I.E.
1=1/4”
2=1/2”
3=3/4”
Using the number above as an example (H1104 0081 2). This hose requires a 37° JIC, female swivel fitting
on one end. A medium length 90° JIC, female swivel fitting for the other end. The Hose must meet or exceed
S.A.E. 100R13 hose specification, and be a total of 81-1/2” long. NOTE: Hose ends and hose must be from
same manufacturer per S.A.E. J1273 Nov. ‘91, Sections 3.10 and 4.2. Hose ends and hose must be of the
same size i.e. #4 size fittings must be used with #4 size hose.
SIZE 03 04 06 08 10 12 16 20 24 32 40 48 56 64
ID 3/16” 1/4” 3/8” 1/2” 5/8” 3/4” 1” 1-1/4” 1-1/2” 2” 2-1/2” 3” 3-1/2” 4”
Hose Size Chart
HOSE PREFIX HOSE END FITTING HOSE END FITTING
S.A.E. HOSE
SPECIFICATION
H01 FEMALE, 37º JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H02 FEMALE, 37º JIC, SWIVEL FEMALE, 37º JIC, SWIVEL 100R13
H03 FEMALE, 37º JIC, SWIVEL 45º, FEMALE, 37º JIC, SWIVEL 100R17
H04 FEMALE, 37º JIC, SWIVEL 45º, FEMALE, 37º JIC, SWIVEL 100R13
H05 FEMALE, 37º JIC, SWIVEL LONG 90º, FEMALE, 37º JIC, SWIVEL 100R17
H06 FEMALE, 37º JIC, SWIVEL SHORT 90º, FEMALE, 37º JIC, SWIVEL 100R17
H07 LONG 90º, FEMALE, 37º JIC, SWIVEL LONG 90º, FEMALE, 37º JIC, SWIVEL 100R17
H08 FEMALE, 37º JIC, SWIVEL FEMALE, 37º JIC, SWIVEL 100R4
H09 FEMALE, 37º JIC, SWIVEL 45º, FEMALE, 37º JIC, SWIVEL 100R4
H10 FEMALE, 37º JIC, SWIVEL MALE PIPE THREAD FITTING 100R17
H11 FEMALE, 37º JIC, SWIVEL MEDIUM 90º, FEMALE, 37º JIC, SWIVEL 100R13
H12 SHORT 90º, FEMALE, 37º JIC, SWIVEL SHORT 90º, FEMALE, 37º JIC, SWIVEL 100R17
H13 FEMALE, 37º JIC, SWIVEL REUSABLE MALE PIPE THREAD FITTING 300 PSI
H14 REUSABLE MALE PIPE THREAD FITTING NO FITTING 300 PSI
H15 REUSABLE, FEMALE, 37º JIC, SWIVEL REUSABLE, FEMALE, 37º JIC, SWIVEL 300 PSI
Fitting Arrangement Schedule (Continued on the following page)

Skyjack SJ51AJ Specifications

General

Brand	Skyjack
Model	SJ51AJ
Category	Boom Lifts
Language	English
