Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 217
9.6 Cold Start Option
M148688AD
L2
L3
L1
1
4
6 7
5
3
2
8
Index
No.
Skyjack
Part No.
Qty. Description
A 167856 - COLD START OPTION (ANSI/CSA - GM)
B 167859 - COLD START OPTION (ANSI/CSA - Deutz D2.9)
C 167853 - COLD START OPTION (CE & AS - Deutz D2011)
D 171127 - COLD START OPTION (ANSI/CSA - Kubota)
1 703290 1 • BLANKET, Battery
2 159888 1 • CORD, “W”
3 164762 1 • HEATER, Pad - 500W
4 144727 2 • TIEWRAP, Cable (43.3”)
5 152402 2 • CLAMP, Tube (Cushioned)
6 103473 2 • BOLT, Hex head (3/8”-16 x 1.00, grade 5)
7 103472 3 • WASHER, Flat, 3/8”
8 104606 1 • NUT, Hex head nylon lock (3/8”-16, grade 5)
9 (Ref.) - • OIL
(For components, refer to Section 11.1)
10 (Ref.) - • COOLANT, Antifreeze
(For components, refer to Section 11.1)
11 (Ref.) 1 • LOAD CIRCUIT ASSEMBLY (not shown), B
(For components, refer to Section 9.8)
L1 143593 1 • LABEL, Shell Telus T46 (located on hydraulic tank)
L2 146021 1 • LABEL, Hydraulic oil/battery warmer (located on W cord)
L3 146162 1 • LABEL, Cold weather factory oil (located on dipstick), B, C
AB
