Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 123
6.1 Base Assembly
AE
Index
No.
Skyjack
Part No.
Qty. Description
A 210404 - BASE ASSEMBLY - serial number 95 002 085 & above
B 168155 - BASE ASSEMBLY - serial number 95 002 084 & below
1 210405 1 • WELDMENT, Base, A
169608 1 • WELDMENT, Base, B
2 148705 1 • GEAR, Ring
3 (Ref.) 2 • AXLE LOCK CYLINDER ASSEMBLY
(For components, refer to Section 3.8)
4 161172 2 • COVER, Chassis
5 103069 2 • FITTING, Straight (06 JICM - 06 ORBM)
6 126128 2 • FITTING, Straight (04 JICM - 04 ORBM)
7 149377 1 • BRACKET, Rotary manifold stop
8 149024 18 • SPACER
9 700782 18 • WASHER, Flat hardened (5/8”)
10 701762 18 • BOLT, Hex head (5/8”-11 x 4.5”, Grade 8)
11 103472 8 • WASHER, Flat (3/8”)
12 103473 8 • BOLT, Hex head (3/8”-16 x 1.00”, Grade 5)
13 207654 8 • BOLT, Hex head patch (1/2”-13 x 2.25”, Grade 8)
14 104379 8 • WASHER, Flat hardened (1/2”)
15 131697 1 • FITTING, Tee (04 JICM - 04 JICM - 04 JICM)
16 707041 1 • FITTING, Straight (06 JICF - 04 JICM)
17 131704 1 • FITTING, Tee (06 JICM - 06 JICM - 06 JICM)
18 159294 8 • NUT, Speed clip (3/8”-16)
- 210408 1 HOSE TRAY ASSEMBLY - serial number 95 002 085 & above
19 208638 1 • PLATE, Botton rear
20 208639 1 • PLATE, Bottom front
21 2089475 8 • BOLT, Hex head (0.375”-16 x 1.625 gr 5)
22 127067 8 • WASHER, Flat (0.375” BB)
23 103472 8 • WASHER, Flat (0.375”)
24 104606 8 • NUT, Lock (0.375”-16 gr 5 nylon)
