Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 127
6.3 Rear Axle Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 148916 - REAR AXLE ASSEMBLY (with gear box)
1 141078 2 • CASE, Axle
2 141079 32 • BOLT
3 141082 2 • SEAL
4 141018 2 • SEAL
5 141019 4 • BEARING
6 141021 16 • STUD, Wheel
7 141020 2 • HUB, Wheel
8 140970 2 • O-RING
9 154590 16 • NUT
10 140969 4 • PLUG
11 141033 4 • BOLT, Countersunk
12 141081 2 • PLATE, Locking
13 141027 16 • NUT
14 141026 16 • STUD
15 140968 2 • PLUG, Magnet
16 141080 2 • SHAFT, Half
- (Ref.) - • DIFFERENTIAL ASSEMBLY
(For components, refer to Section 6.4)
- (Ref.) - • BRAKES - REAR AXLE
(For components, refer to Section 6.5)
- (Ref.) - • CENTRAL HOUSING ASSEMBLY
(For components, refer to Section 6.6)
K1 141042 2 KIT, Ring gear support
K2 141034 2 KIT, Planet gear carrier
