Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 129
6.4 Differential Assembly - Rear Axle
Index
No.
Skyjack
Part No.
Qty. Description
1 140977 4 BOLT
2 141068 2 NUT, Ring
3 151768 2 BOLT
4 140993 12 BOLT
5 141065 1 GEAR SET, Bevel
6 140987 2 BEARING, Taper roller
7 154576 1 BOOT
8 154577 1 SWITCH, Security
9 154589 1 WASHER, Seal
10 154578 1 WASHER, Seal
11 154580 1 NUT
12 154579 1 O-RING
13 154588 1 SELECTOR FORK
14 154587 1 CIRCLIP
15 154586 1 PLUG
16 154585 1 SPRING
17 154571 1 CIRCLIP
18 154584 1 PISTON
19 154583 1 O-RING
20 154575 1 RING
21 140966 1 CIRCLIP
22 140980 1 RING NUT
23 140984 2 BEARING, Taper roller
24 141063 1 COVER
25 141075 8 WASHER, Spring
26 141076 8 BOLT, Hexagon
27 141064 1 O-RING
28 141062 1 SPACER
29 141074 1 SEAL
30 141072 12 BOLT, Hexagon
31 154574 6 BALL, Detent
32 154582 1 SELECTOR
33 154572 1 KEY
34 154581 1 SHEET
K1 140982 1 KIT, Shim
K2 140983 1 KIT, Shim
K3 154573 1 KIT, Differential position
