Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 13
1.2 Railings & Base
AD
Index
No.
Skyjack
Part No.
Qty. Description
A 161002 1 PLATFORM ASSEMBLY (30” x 60”) ANSI/CSA
B 161003 1 PLATFORM ASSEMBLY (30” x 60”) CE & AS
C 161004 1 PLATFORM ASSEMBLY (30” x 72”) ANSI/CSA
D 161005 1 PLATFORM ASSEMBLY (30” x 72”) CE & AS
1 160959 1 • BASE, Platform A
160960 1 • BASE, Platform B
160961 1 • BASE, Platform C
160962 1 • BASE, Platform D
2 160996 1 • RAILING, Front left A, B
160997 1 • RAILING, Front left C, D
3 160998 1 • RAILING, Front right, A, B
160999 1 • RAILING, Front right C, D
4 165823 1 • RAILING, Rear A, B
165820 1 • RAILING, Rear C, D
5 100702 6 • CAP, Plastic end
6 149098 1 • RAILING, Front
7 159586 1 • PLATE, Front guard
8 198789 1 • MANUAL BOX
9 103984 18 • NUT, Centerlock (5/16”-18 Grade 8)
10 115649 4 • NUT, Hex lock (1/4”-20 Grade 5, nylon)
11 103996 36 • WASHER, Flat (5/16”)
12 103995 4 • WASHER, Flat (1/4”)
13 139008 4 • SCREW, Round head machine (5/16”-18 x 2”)
14 103632 4 • SCREW, Hex head self tapping (1/4”-14 x 3/4”)
15 103866 4 • BOLT, Hex head (5/16”-18 x 2 1/4” Grade 5)
16 103856 4 • BOLT, Hex head (1/4”-20 x 3/4” Grade 5)
17 103865 10 • BOLT, Hex head (5/16”-18 x 2” Grade 5)
18 700598 4 • WASHER, Fender
19 (Ref). 1 • LOAD CELL
B, D
(For components, refer to Section 1.5)
