Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 131
6.5 Brake Assembly - Rear Axle
Index
No.
Skyjack
Part No.
Qty. Description
1 141096 10 BRAKE DISC, Intermediate
2 141108 8 DISC, Brake
3 141097 6 BOLT, Adjusting
4 151757 1 PISTON (Right)
151758 1 PISTON (Left)
5 141098 3 • SPRING
6 141109 1 • PISTON (Right)
141099 1 • PISTON (Left)
7 141101 1 • O-RING
8 151759 2 • PUSHER
9 141107 1 • O-RING
10 141102 2 DOWEL
11 141085 1 LEVER (Right)
141103 1 LEVER (Left)
12 141089 2 BUSHING, Reduction
13 141006 2 PLUG
14 141086 2 BOLT, Bleeding
15 141104 6 SPRING
16 141129 2 O-RING
17 141088 2 O-RING
18 141091 2 NUT
19 141090 2 BOLT
20 141087 6 BOLT
21 141092 2 O-RING
22 141093 1 LEVER
23 141094 2 WASHER
24 141095 2 BOLT, Countersunk
25 141112 1 FITTING, Grease
26 141110 1 LEVER
27 139126 1 SEAL, British bonded
28 149195 1 FITTING, Elbow 90˚ (04 JICM - 04 BSPPM)
29
141123 1 CYLINDER, Wheel
30 141122 1 NUT
31 141121 1 CIRCLIP
32 141113 2 WASHER
33 141119 1 BUSHING, Reduction
34 141124 1 BUSHING, Reduction
35 141118 4 BALL, Detend
36 141117 1 CAM, Brake
37 141116 1 SPRING
38 141115 1 BUSHING, Reduction
Parts list continued from the previous page.
