Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 141
6.9 Front Axle Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 148701 - FRONT AXLE ASSEMBLY
1 154624 2 • BUSHING, Thrust
2 154625 4 • SEAL
3 154626 2 • JOINT
4 141006 4 • PLUG
5 141014 4 • FITTING, Grease
6 140993 20 • BOLT
7 151765 2 • BUSHING
8 154630 1 • CASE, Steering (Left)
154629 1 • CASE, Steering (Right)
9 154632 16 • STUD, Wheel
10 141168 16 • NUT
11 154631 2 • SEAL
12 154638 4 • BEARING
13 154639 2 • HUB, Wheel
14 140970 2 • O-RING
15 154637 16 • STUD
16 154636 16 • NUT
17 154634 2 • PLATE, Locking
18 154635 2 • SPACER
19 141036 2 • CIRCLIP
20 141033 4 • BOLT, Countersunk
21 140969 2 • PLUG
K1 154628 2 • KIT, Pivot pin
K2 141034 2 • KIT, Planet gear carrier
K3 154633 2 • KIT, Ring gear support
K4 154627 2 • KIT, Shim
K5 141017 4 • KIT, Steering adjust bolt
