Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 161
7.2 Deutz D2011 Diesel Engine
AD
Index
No.
Skyjack
Part No.
Qty. Description
- 167239 1 ENGINE ASSEMBLY - Deutz D2011
1 167801 1 • ENGINE, Diesel (Deutz D2011 L03i)
127181 1 • • PUMP, Fuel injection
127182 1 • • CAP, Filler
127183 1 • • FLYWHEEL
127184 1 • • CONNECTOR, Plug-in
127185 1 • • CONNECTOR, Plug-in
127186 1 • • CABLE, Interconnect
204249 1 • • STARTER
127188 1 • • EXHAUST, Silencer
127189 1 • • V-BELT, Narrow
147071 1 • • FILTER, Fuel
147072 1 • • FILTER, Oil
157647 1 • • ACTUATOR, Engine shutdown
157748 1 • • DIPSTICK
2 139254 1 • FILTER, In-line fuel
3 152424 1 • SUPPORT, Exhaust stack
4 136030 1 • CLAMP, Exhaust (1.875” diameter)
5 (Ref.) - • ENGINE COUPLING ASSEMBLY
(For components, refer to Section 7.8)
6 167254 1 • DEFLECTOR, Air
7 167216 1 • STACK, Exhaust
8 149208 1 • REDUCER, Air intake
9 167498 1 • TUBE, Air intake
10 163244 1 • BRACKET, Air cleaner
11 163250 1 • INDICATOR, Service
12 163247 1 • CONNCTOR, 90°
13 103996 4 • WASHER, Flat (5/16”)
14 103885 2 • BOLT, Hex head (5/16”-18 x 1.25” Grade 5)
15 103906 2 • BOLT, Hex head (1/2”-13 x 1.75” Grade 5)
16 104379 14 • WASHER, Flat hardened (1/2”)
17 702507 8 • NUT, Hex head nylon lock (1/2”-13 Grade 5)
18 111420 4 • BOLT, Hex head (1/2”-13 x 4.50” Grade 5)
19 133232 7 • WASHER, Flat (M8 DIN125)
20 104608 2 • BOLT, Hex head (M6 x 1 x 16mm, Grade 9.8)
21 133869 3
• BOLT, Hex head (ZP, M8 x 1.25 x 25mm, Grade 8.8)
22 133174 1 • BOLT, Hex head (ZP, M8 x 1.25 x 20mm, Grade 8.8)
23 116342 2 • CLAMP, Gear (SAE No. 8, 7/16” - 1”)
24 121869 3 • CLAMP, Gear (SAE No. 40, 2-1/6” - 3”)
25 138666 1 • CLAMP, Gear (SAE No. 54, 3-1/6” - 4”)
26 163242 1 • AIR CLEANER
165947 1 • • FILTER ELEMENT, Primary
165948 1 • • FILTER ELEMENT, Secondary
Parts list continued from the previous page.
