Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 183
7.7 Drive and System Pump Assembly (with Welder Option)
AB
Index
No.
Skyjack
Part No.
Qty. Description
- 165046 - DRIVE AND SYSTEM PUMP ASSEMBLY (for machines with Welder Option)
1 170599 1 • PUMP ASSEMBLY, Drive (for serial number 95 001 292 & above) - A
161686 1 • PUMP ASSEMBLY, Drive (for serial number 95 001 291 & below) - B
2 162330 1 • PUMP, Tandem gear 46AJ
3 162387 1 • O-RING (3.25” ID x 1/16”)
4 103999 2 • WASHER, Lock (3/8”)
5 101297 2 • BOLT, Hex head (3/8”-16 x 1-1/4” Grade 5)
6 103470 2 • WASHER, Lock (1/2” Grade 5)
7 104379 2 • WASHER, Flat (1/2” Hardened)
8 103907 2 • BOLT, Hex head (1/2”-13 x 1-1/2” Grade 5)
9 137630 1 • FITTING, Straight (10 JICM - 10 ORBM)
10 702118 1 • FITTING, Straight (12 JICM - 12 ORBM), A
144279 1 • FITTING, Straight (08 ORBM - 12 JICM), B
11 162044 1 • FITTING, Tee (04 JICM - 04 JICM - 06 JICM)
12 148490 1 • FITTING, Branch Tee (06 SAEM - 04 JICM - 04 JICM)
13 710124 2 • FITTING, 90° (12 JICM - 16 ORBM)
14 162043 1 • FITTING, Straight (08 ORBM - 06 JICFS)
15 131286 3 • FITTING, Cap (04 JICF)
16 160885 1 • FITTING, Straight (06 ORBM - 04 JICFS)
17 131697 1 • FITTING, Tee (04 JICM - 04 JICM - 04 JICM)
18 707040 1 • FITTING, 90° (16 JICM - 16 ORBM)
19 165074 1 • FITTING, 45° (16 JICM - 20 ORBM)
20 149215 1 • FITTING, 45° (10 JICM - 10 ORBM)
K1 160637 1 SEAL KIT, Drive Pump
