Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 191
8.2 Hydraulic Hose Connection - Boom
Index
No.
Skyjack
Part No.
Qty. Description
25 134835 2 FITTING, Straight (04 JICM - 04 JICM) (component of Riser Hose Kit)
26 131732 48” SLEEVE, Nylon hose protection (componen of E-Chain Hose Kit)
Index
No.
Hose
P/N
From To
Description Port Port Description
- 167647 JIB HOSE KIT
1 H3104 0031 0 Bulkhead 2 (Rotary Actuator) L 1A Jib Manifold
2 H3104 0031 0 Bulkhead 2 (Rotary Actuator) R 2A Jib Manifold
3 H3104 0018 0 Jib Manifold 1B R Jib Cylinder
4 H3104 0018 0 Jib Manifold 2B E Jib Cylinder
5 H3404 0013 0 Rotary Actuator P1 R Bulkhead (Rotary Actuator)
6 H3404 0013 0 Rotary Actuator P2 L Bulkhead (Rotary Actuator)
- 169596 E-CHAIN HOSE KIT (SJ46AJ)
- 169569 E-CHAIN HOSE KIT (SJ51AJ)
7 H3104 0219 0 Master Cylinder (SJ46AJ) E - Bulkhead 1 (Fly Boom)
H3104 0283 0 Master Cylinder (SJ51AJ) E - Bulkhead 1 (Fly Boom)
8 H3104 0230 0 Master Cylinder (SJ46AJ) R - Bulkhead 1 (Fly Boom)
H3104 0298 0 Master Cylinder (SJ51AJ) R - Bulkhead 1 (Fly Boom)
9 H3104 0267 0 Jib Manifold (SJ46AJ) 3B - Union
H3104 0324 0 Jib Manifold (SJ51AJ) 3B - Union
10 H3104 0267 0 Jib Manifold (SJ46AJ) 4A - Union
H3104 0324 0 Jib Manifold (SJ51AJ) 4A - Union
11 H3104 0028 2 Slave Cylinder E - Bulkhead 1 (Fly Boom)
12 H3104 0028 2 Slave Cylinder R - Bulkhead 1 (Fly Boom)
- 149103 RISER HOSE KIT
13 H3104 0380 0 Main Manifold PL1 E Master Cylinder
14 H3104 0360 0 Main Manifold PL2 R Master Cylinder
15 H3104 0380 0 Main Manifold P1 E Boom Lift Cylinder
16 H3104 0374 0 Main Manifold P2 R Boom Lift Cylinder
17 H3104 0392 0 Main Manifold JBP - Union
18 H3104 0392 0 Main Manifold JBT - Union
19 H3206 0144 0 Check Valve CV2 E Riser Cylinder - RH
20 H3104 0144 0 Main Manifold S2 R Riser Cylinder - LH
21 H3106 0031 0 Riser Cylinder LH - Return R R Riser Cylinder RH - Return
22 H3106 0031 0 Riser Cylinder LH - Return E E Riser Cylinder RH - Return
23 H3106 0346 0 Main Manifold RET R Extension Cylinder
24 H3106 0346 0 Main Manifold EXT E Extension Cylinder
