Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 193
8.3 Hydraulic Hose Connection - Manifolds & Swing Drive (S/N 95 002 084 & below)
AE
Index
No.
Hose
P/N
From To
Description Port Port Description
- 166742 TURRET HOSE KIT - serial number 95 001 717 to 95 002 084
1 H3404 0039 0 Main Manifold ST1 1 Rotary Manifold
2 H3404 0041 0 Main Manifold ST2 5 Rotary Manifold
3 H3404 0054 0 Main Manifold SW1 A Swing Drive
4 H3404 0054 0 Main Manifold SW2 B Swing Drive
5 H3206 0012 2 Main Manifold S1 2 Check Valve
6 H3404 0037 0 Brake Manifold AL 2 Rotary Manifold
7 H3404 0037 0 Brake Manifold BRG 4 Rotary Manifold
8 H3404 0034 0 Brake Manifold D 10 Rotary Manifold
9 H3408 0057 0 Rotary Manifold 9 T6 Hydraulic Tank
10 H3106 0016 0 Check Valve Assembly 1 2 Check Valve Assembly
11 H5404 0046 0 Brake Manifold 2SPD 6 Rotary Manifold
12 131732 Nylon Sleeve (“13)
Serial number 95 001 716 & below
13 H3401 0024 0 Pressure Reducing Manifold 1 6 Rotary Manifold
14 H3404 0018 0 Pressure Reducing Manifold 2 2SPD Brake Manifold
15 H3404 0013 0 Pressure Reducing Manifold 3 T3 Hydraulic Tank
