Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 195
8.4 Hydraulic Hose Connection - Pumps (S/N 95 002 084 & below)
Index
No.
Hose
P/N
From To
Description Port Port Description
- 166807 DRIVE PUMP HOSE KIT - serial number 95 002 084 & below
1 H3712 0062 0 Drive Pump D2 T5 Hydraulic Tank (P. Case Drain)
2 H4004 0080 0 Drive Pump Ma M1 Brake Manifold
3 H4004 0080 0 Drive Pump Mb M2 Brake Manifold
4 H3816 0057 0 Drive Pump S T2 Hydraulic Tank (Drive Suction)
5 H3404 0062 0 Drive Pump C1 3 Rotary Manifold
6 H0412 0053 0 Drive Pump A 8 Rotary Manifold
7 H0412 0050 0 Drive Pump B 7 Rotary Manifold
8 131732 Sleeve, Nylon (24”) - -
9 131732 Sleeve, Nylon (19”) - -
10 131732 Sleeve, Nylon (13”) - -
11 131732 Sleeve, Nylon (24”) - -
- 166841 SYSTEM & AUXILIARY PUMP HOSE KIT
12 H3916 0059 0 System Pump (Suction) OUT T1 Hydraulic Tank
13 H3204 0042 0 Main Manifold P LS Brake Manifold
14 H1708 0007 0 Hydraulic Tank (H.P. Suction) T4 IN Auxiliary Pump
15 H3404 0034 0 Auxiliary Pump OUT AUX Main Manifold
16 H5106 0018 0 Brake Manifold T T3 Main Manifold
17 144087 Straight Fitting (08 BARB - 08 JICFS)
18 144094 Hose Clamp (19-21 Mikalor)
- 166752 NO OIL COOLER HOSE HOSE
19 H5112 0030 0 Return Filter IN T1 Main Manifold
20 H5108 0086 0 Pressure Filter OUT P Main Manifold
21 H5410 0039 0 Pressure Filter IN
- System Pump
AE
