Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 197
AE
8.5 Hydraulic Hose Connection - Turret (S/N 95 002 085 & above)
Index
No.
Hose
P/N
From To
Description Port Port Description
- 211209 TURRET HOSE KIT (with hoses from 8.6) - serial number 95 002 085 & above
1 H3404 0054 0 Main Manifold SW1 A Swing Drive
2 H3404 0054 0 Main Manifold SW2 B Swing Drive
3 H3206 0012 2 Main Manifold S1 2 Check Valve
4 H3106 0016 0 Check Valve 1 2 Check Valve
- 166841 SYSTEM & AUXILIARY PUMP HOSE KIT
5 H3916 0059 0 System Pump (Suction) OUT T1 Hydraulic Tank
6 H3204 0042 0 Main Manifold P LS Brake Manifold
7 H1708 0007 0 Hydraulic Tank (H.P. Suction) T4 IN Auxiliary Pump
8 H3404 0034 0 Auxiliary Pump OUT AUX Main Manifold
9 H5106 0018 0 Brake Manifold T T3 Main Manifold
10 144087 Straight Fitting (08 BARB - 08 JICFS)
11 144094 Hose Clamp (19-21 Mikalor)
- 166752 NO OIL COOLER HOSE KIT
12 H5112 0030 0 Return Filter IN T1 Main Manifold
13 H5108 0086 0 Pressure Filter OUT P Main Manifold
14 H5410 0039 0 Pressure Filter IN - System Pump
To Next Page
