Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 199
8.6 Hydraulic Hose Connection - Base (S/N 95 002 084 & below)
Index
No.
Hose
P/N
From To
Description Port Port Description
163574 CHASSIS HOSE KIT - serial number 95 002 084 & below
1 H3104 0031 0 Axle Lock - Pilot Right - - Axle Lock - Pilot Tee
2 H3106 0031 0 Axle Lock - Pressure Left - - Axle Lock - Pressure Tee
3 H3106 0031 0 Axle Lock - Pressure Right - - Axle Lock - Pressure Tee
4 H3104 0031 0 Axle Lock - Pilot Left - - Axle Lock - Pilot Tee
5 H3204 0047 0 Rotary Manifold 1 - Steer Cylinder - Right
6 H3104 0035 0 Rotary Manifold 2 - Axle Lock - Pilot Tee
7 H3404 0032 2 Rotary Manifold 3 - Axle Lock - Pressure Tee
8 H3404 0056 2 Rotary Manifold 4 - Rear Axle - Brake Cylinder
9 H3204 0047 0 Rotary Manifold 5 - Steer Cylinder - Left
10 H3404 0052 0 Rotary Manifold 10 - Rear Axle - Differential Lock
11 H3404 0032 2 Rotary Manifold 6 X1 Drive Motor
12 H3108 0022 0 Rotary Manifold 9 L1 Drive Motor
13 H0212 0022 0 Rotary Manifold 7 B Drive Motor
14 H0212 0027 0 Rotary Manifold 8 A Drive Motor
