Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 201
8.7 Hydraulic Hose Connection - Base (S/N 95 002 085 & above)
Index
No.
Hose
P/N
From To
Description Port Port Description
211212 CHASSIS HOSE KIT - serial number 95 002 085 & above
1 H3104 0031 0 Axle Lock - Pilot Right - - Axle Lock - Pilot Tee
2 H3106 0031 0 Axle Lock - Pressure Left - - Axle Lock - Pressure Tee
3 H3106 0031 0 Axle Lock - Pressure Right - - Axle Lock - Pressure Tee
4 H3104 0031 0 Axle Lock - Pilot Left - - Axle Lock - Pilot Tee
- 211210 DRIVE PUMP HOSE KIT - serial number 95 002 085 & above
5 H3712 0062 0 Drive Pump D2 T5 Hydraulic Tank (P. Case Drain)
6 H4004 0080 0 Drive Pump Ma M1 Brake Manifold
7 H4004 0080 0 Drive Pump Mb M2 Brake Manifold
8 H3816 0057 0 Drive Pump S T2 Hydraulic Tank (Drive Suction)
9 H3104 0122 0 Drive Pump C1 - Axle Lock - Pressure Tee
10 H0412 0152 0 Drive Pump A A Drive Motor
11 H0412 0152 0 Drive Pump B B Drive Motor
12 140914 Sleeve, Protective (140”)
13 140914 Sleeve, Protective (140”)
14 131732 Sleeve, Nylon (24”)
15 131732 Sleeve, Nylon (19”)
16 131732 Sleeve, Nylon (13”)
211209 TURRET HOSE KIT (with hoses from 8.5) - serial number 95 002 085 & above
17 H3204 0120 0 Steering Cylinder R ST1 Main Manifold
18 H3204 0120 0 Steering Cylinder L ST2 Main Manifold
19 H3404 0103 0 Axle Lock - Pilot Tee - AL Brake Manifold
20 H3404 0149 0 Rear Axle - Brake - BRG Brake Manifold
21 H3404 0147 0 Rear Axle - Diff Lock - D Brake Manifold
22
H3108 0118 0 Motor L1 T6 Hydraulic Tank
23 H3404 0111 0 Motor X1 2SPD Brake Manifold
24 131732 Sleeve, Nylon (13”)
